Maintenance-free LED explosion-proof lights XL128FB-T1

Product introduction
The input voltage: 220V/50HZ

Explosion-proof marks: Exd II C T5 Gb

source type: LED

Power: 20-60W

Protection Grade: IP66

The anti-corrosion: WF1/WF2

Inlet thread: G3/4"

F150W-1
F70-100W-1
微信图片_20251119165433_886_4
F150W-1
F70-100W-1
微信图片_20251119165433_886_4
Product details

Scope of application

Suitable for anti-explosive gas environment zone 1, 2;

Suitable for IIA.IIB.IIC explosive gas environment;

Suitable for combustible dust environment zone 21, 22;

Applicable to the temperature classification of T1~T6 environment;

Suitable for oil production, refining, storage, chemical, medical, textile,  military and military facilities and other explosive dangerous environment;

It is compatible with all kinds of explosion-proof lamps and lanterns of our  company.


Technical Parameters

Model

Type

(W)
Power

(lm)
Luminous

h)
Life

XL128FB-T1

LED

20

2200

50000

XL128FB-T1

LED

30

3300

50000

XL128FB-T1

LED

40

4400

50000

XL128FB-T1

LED

50

5500

50000

XL128FB-T1

LED

60

6600

50000

XL128FB-T1

LED

70

7700

50000

XL128FB-T1

LED

80

8800

50000

XL128FB-T1

LED

100

11000

50000

XL128FB-T1

LED

120

13200

50000

XL128FB-T1

LED

150

16500

50000

XL128FB-T1

LED

200

22000

50000
